The AC-MX-42 is a true 4x2 HDMI matrix switch. Supporting HDMI 2.0(a/b), HDCP 2.2, up to 4K video resolution, and up to 18 Gbps bandwidth. This switch allows any source (Blu-ray, UHD Blu-ray, satellite receiver, game consoles, PCs, etc ... ) to be shown on any of the connected displays. This matrix equalizes and amplifies the output to ensure the HDMI signal can be transmitted through long HDMI cables without loss of quality.
The AC-MX-42 is ideal for bypassing AVR"s that do not support full 18Gbps. You can bypass uncompressed HDMI to the display while running down-scaled video into a legacy AVR. Only video is reduced and audio remains untouched, making it an ideal component for systems where high bit rate audio is critical.
Conference room all-star. The auto-switching feature makes this unit an ideal, affordable, component for any conference room system. Ideal for feeding a video signal into a video conferencing codec with very little setup.
This is an ideal solution for digital entertainment centers, HDTV retail, show sites, data centers, schools, conference and training centers and more!
Features:
• HDMI 2.0(a/b)
• 18Gbps Bandwidth Support
• 4K60 4:4:4 Support
• Full HDR Support (HDR 10 & 12 Bit)
• Dolby Vision, HDR10+ and HLG Support
• HDCP 2.2 (and all earlier versions supported)
• 4K > 1080p Down Scaler (Out 2)
• Perfect AVR Bypass deliver 18Gbps to Display and uncompressed audio to AVR
• Advanced EDID Management
• IR, RS-232 and LAN Control Options
• Digital Toslink Out (7CH PCM, DD, DD+, DTS, DTS-MA)
• Balanced Analog Out (2CH PCM)
• Down-scaling mode for mixed systems
• Driver Support for Crestron, C4, RTI, ELAN and more
• Extracted Audio Supports DD+, DTS Master Audio on Toslink
• Extracted Audio bound to output 1 or 2
• AVR Mirror Mode - Mirrored Outputs
The AC-MX-42 is ideal for bypassing AVR"s that do not support full 18Gbps. You can bypass uncompressed HDMI to the display while running down-scaled video into a legacy AVR. Only video is reduced and audio remains untouched, making it an ideal component for systems where high bit rate audio is critical.
Conference room all-star. The auto-switching feature makes this unit an ideal, affordable, component for any conference room system. Ideal for feeding a video signal into a video conferencing codec with very little setup.
This is an ideal solution for digital entertainment centers, HDTV retail, show sites, data centers, schools, conference and training centers and more!
Features:
• HDMI 2.0(a/b)
• 18Gbps Bandwidth Support
• 4K60 4:4:4 Support
• Full HDR Support (HDR 10 & 12 Bit)
• Dolby Vision, HDR10+ and HLG Support
• HDCP 2.2 (and all earlier versions supported)
• 4K > 1080p Down Scaler (Out 2)
• Perfect AVR Bypass deliver 18Gbps to Display and uncompressed audio to AVR
• Advanced EDID Management
• IR, RS-232 and LAN Control Options
• Digital Toslink Out (7CH PCM, DD, DD+, DTS, DTS-MA)
• Balanced Analog Out (2CH PCM)
• Down-scaling mode for mixed systems
• Driver Support for Crestron, C4, RTI, ELAN and more
• Extracted Audio Supports DD+, DTS Master Audio on Toslink
• Extracted Audio bound to output 1 or 2
• AVR Mirror Mode - Mirrored Outputs
