** Förstärkaren startar, men ingen signal går igenom **

Gear4music's 1 års garanti för begagnade produkter gäller ej.

Produktinformationen kan innehålla tillbehör eller programvara som inte ingår i Tradera varan.

Det som syns på annonsens bilder är det som medföljer, om annat inte anges i vår produktbeskrivning.

Observera att produkten inte är tillgänglig för avhämtning från Gear4musics Showroom utan kommer att skickas som hemleverans.

Följande är den ursprungliga produktbeskrivningen, ENDAST FÖR REFERENS.

Full Description

Inspired by a classic levelling amp/compressor
Basing its design on one of the most sought-after compressors ever made, the 2A-KT draws inspiration from the original, with a range of upgrades and enhancements. At the heart of the 2A-KT is a range of high-end tubes comprised of the 12AX7, 12BH7 and EL84. The 2A-KT also employs a lag-free optical attenuator based on electroluminescent technology with custom-built Midas I/O transformers for optimal signal integrity.

Vintage tonality with classic tube warmth
Employing hand-selected tubes, the 2A-KT delivers the same classic warmth associated with the original compressor design. The combination of the 12AX7, 12BH7 and EL84 tubes delivers an ultra-low-noise analog output, providing the perfect balance of tight warm bass with a smooth midrange and a bright, airy treble.

Its wide frequency response ranges from 10Hz to 20kHz, capturing every nuance of your sound source with incredible sonic accuracy and detail. It also boasts a fast attack time of 10 milliseconds and a release time from 50 milliseconds to five full seconds. You can also instantly switch between limiting and compression with the dedicated switch. You can even link two 2A-KTs together to blend their sidechain signals for a shared threshold between the two units.

Enhanced design for modern users
Taking the original design a step further, the 2A-KT features a range of high-end discrete components that help to enhance the usability of the levelling amp/compressor. One of the most unique features is the variable pre-emphasis trimmer which is designed to adjust the sidechain that the compressor responds to whilst not affecting the audio directly. The peak reduction knob controls the threshold of the compressor/limiter with a maximum of 40dB gain reduction for a wide range of applications.

Features
Classic tube compressor/levelling amplifier modeled after the iconic Teletronix LA-2A
Completely discrete signal path
Premium selection 12AX7, 12BH7 and EL84 tubes
Lag-free optical attenuator based on original electroluminescent technology
Custom-built MIDAS input and output transformers10Hz - 20kHz (±1dB) frequency response
0dB to 30dB gain limiting
Ultra-fast attack time
Adjustable stereo-link connection
Variable pre-emphasis for digital audio recording and broadcasting transmission
Vintage-style meter features gain reduction and output
Transformer balanced inputs and outputs on Neutrik XLR connectors
Rugged 2U rackmount chassis for durability in portable applications
Auto-ranging universal switch-mode power supply
Designed and engineered in the U.K.
Specifications
Audio Input
Audio Input Type: XLR, 1/4" TRS, Transformer Balanced
Input Impedance: 600 O, Balanced And Unbalanced
Maximum Input Level: +20 dBu, Balanced And Unbalanced
CMRR at 1 kHz: Typically -80 dB
Audio Output
Type: XLR, 1/4" TRS, Transformer Balanced
Impedance: 70 O, Balanced And Unbalanced
Maximum Output Level: +18 dBu, Balanced And Unbalanced
System
Frequency Response: 10 Hz To 20 kHz, ±1 dB
Noise At Unity Gain: -87 dBu, Unweighted, 20 Hz To 20 kHz
THD At Unity Gain: 0 dBu Input Level Typically <0.1 percent 20 Hz To 20 kHz
Compressor
Attack Time: Typically 10 ms
Release Time: Typically 50 ms For 50 percent Release, Up To 5 s For Full Release
Maximum Output Gain: +30 dB
Maximum Peak Reduction: -30 dB
Tube Types: 2x 12AX7, 1x 12BH7, 1x EL84
Meter Settings: Gain Reduction, +4 Output, +10 Output
Power Supply
Mains Voltage: 100 – 240 V~, 50/60 Hz
Power Consumption: 30 W
Fuse: T1AH 250 V
Mains Connection: Standard IEC Receptacle
Physical
Dimensions (HxWxD): 88 x 483 x 158 mm (3.5 x 1.9 x 6.2")
Weight: 2.9 kg (6.4 lbs)
Product Code: KT-2A

Se till att du läser artikelbeskrivningen fullständigt eftersom den säljs i befintligt skick.


14 dagars ångerrätt.
Du har 14 dagars ångerfrist från dagen efter att varan mottagits.
Fraktkostnad för returnering av varan betalas av dig som köpare.
