Beskrivning

Defekt

Fungerar ej på grund av att den har fastnat i "protection mode"

Gear4music's 1 års garanti för begagnade produkter gäller ej.

Observera att produkten inte är tillgänglig för avhämtning från Gear4musics Showroom utan kommer att skickas som hemleverans. Produkten kommer skickas till adressen hänvisad i köparens kontoprofil.

Produktinformationen kan innehålla tillbehör eller programvara som inte ingår i Tradera varan.

Det som syns på annonsens bilder är det som medföljer.

Observera att produkten inte är tillgänglig för avhämtning från Gear4musics Showroom utan kommer att skickas som hemleverans.

Följande är den ursprungliga produktbeskrivningen, ENDAST FÖR REFERENS.

Full Description

Premium power
Engineered for quality. Lab Gruppen's PDX series has been designed to deliver phenomenal power with outstanding performance and reliability. The PDX3000 provides you with two channels, each capable of producing 1500W of Class-D power, making it ideal for entry- and mid-level PA applications.

The amp utilises Lab Gruppen's unique IDEEA Class-D output stage, which has been precisely matched to the rated power output. What's more, you can use each channel to drive 2, 4, or 8 Ohm loads without having to reconfigure the amp. This is thanks to an intelligent design with plenty of voltage swing and current capacity, and a permanently bridged output.

Flexible processing
Take control. With Lab Gruppen's PDX Controller software, you can configure the PDX3000's DSP to sculpt the perfect sound. Take advantage of the ability to adjust crossovers, cut and boost frequencies with 8-band parametric EQ and 2-band dynamic EQ, adjust delay from 0 to 300ms, protect your sound with the limiter, and more.

You can connect the amp to your computer via the rear-panel USB port, providing you with intuitive and comprehensive control over the PDX3000's processing power. You can control the amp itself via the software too, or you can make use of the intelligently-designed front panel and LCD display. The PDX3000 is ideal for both installed and touring applications, and provides you with the ability to craft your sound with ease.

Built to last
Rugged, rackmountable, and built with premium components. The PDX3000 is in it for the long haul. The chassis itself is crafted from aluminium with a hard-wearing finish, keeping each and every aspect of your amplifier safe. The PDX3000 is also equipped with Neutrik NLT4 SpeakON outputs for reliable connectivity to your loudspeakers. You can easily mount the PDX3000 in a rack case too, so you can store, transport and use your amp with complete confidence.

Features
Two channel power amplifier delivering 2 x 1500W
Full DSP feature set for powerful loudspeaker processing
Proven and reliable Class-D amplifier stage
Highly-efficient switch mode power supply (SMPS)
Comprehensive configuration and monitoring software through USB connection
Intuitive front panel interface for easy setup and monitoring
Precise power management guarantees performance and efficiency
Comprehensive circuit protection against short circuits, DC and thermal overload
User-configurable gain, delay, crossover, EQ, limiter, and dynamic EQ
Speaker Protect Limiter for maximum level output and reliable driver protection
Pre-configured crossover settings for speaker configuration
Balanced XLR and TRS input connectors with optimised sensitivities
Professional Neutrik SpeakON output connectors
Front panel locking functionality for keeping your settings safe
Efficient cooling with temperature-controlled fans
Rugged and lightweight rackmount chassis provides maximum durability
Designed and engineered in Sweden
Covered by Lab Gruppen's 10-year warranty program
Specifications
Channels:
Amplifier: 2
Processing: 2
Peak Output:
Wattage of All Channels Driven: 3000W
Voltage per Channel: 115V
Current per Channel: 32A
Bridge Mode: No
Output Circuit Type: Class-D
Max Output Power: (All channels driven)
2 Ohms per Channel: 1000W
4 Ohms per Channel: 1500W
8 Ohms per Channel: 800W
THD+N:
20Hz-20kHz at 1W: Less than 0.1-percent
At 1kHz, 1dB Below Clip: Less than 0.1-percent
Signal-to-Noise: Greater than 90dB
Channel Separation: Greater than 75dB (crosstalk) (at 1kHz)
Frequency Response: 10Hz - 20kHz, +0.5/-1dB
Input Impedance: 10 k Ohms unbalanced, 20 k Ohms balanced
Internal Sample Rate: 96kHz
Product Propagation Delay: 0.6ms
Distortion: Less than 0.1-percent (1/8 rated power)
Front Controls:
Power switch
Gain (channels A and B)
DSP section rotary push-encoder
Buttons for Process, Setup, Up, Down, Exit
Remote Controls: Via USB for PDX Controller software running on a computer
Display: LCD 128x32, white text on black background
Indicators:
Power: RDY LEDs lit green
Limit: LIM LEDs lit red (per channel)
Signal: -24dB, -12dB, -6dB LEDs lit green (per channel)
Thermal Warning: Per Channel - RDY LED blink orange / 90-percent, PSU - Both RDY LEDs blink orange
Thermal Fault: Per Channel - RDY LED blink red / 100-percent, PSU - Both RDY LEDs blink red
Fault: Channel - RDY LED constantly lit red / Device - Both RDY LEDs constantly lit red
DSP:
Delay: 0-300ms
Crossover: 3 filter types, up to 48dB/oct.
EQ: 8-band parametric, 2-band dynamic
Limiter: Zero attack limiter (peak)
Presets: 20 total presets, 19 user-definable
Input/Link Connectors: 2 x XLR, 2 x 1/4'' TRS
Output Connectors: Neutrik SpeakON (2 x NLT4)
USB Connector: Rear panel USB connector type B for remote control of DSP section with PDX controller software
Mains Connector: Locking IEC appliance inlet, C14
Cooling: Two fans front-to-rear air flow, temperature controller speed
Amplifier Protection: Thermal and DC protection, Rail sensing and peak current limiting
Load Protection: Controlled start and shutdown behaviour, DC-fault protection, Short-circuit protection
Voltage: 220-240V, 50/60Hz
Power Consumption: 1050W (at 4 Ohms, rated power)
Finish: Black painted aluminium chassis and grey front
Approvals: CE, UL (ANSI/UL, CAN/CSA), PSE, RCM, CCC, FCC
Dimensions: 93mm x 483mm x 326mm / 3.7'' x 19'' x 12.8'' (H x W x D)
Weight: 6.5kg / 14.3lbs
Product Code: PDX3000

Se till att du läser artikelbeskrivningen fullständigt eftersom den säljs i befintligt skick.
