Handic 006 Scanner

SPECIFICATIONS
GENERAL
Type: VHF receiver/scanner
Frequency range: 75-85 / 88-108 / 148-174 MHz
Tuning steps: Scanner: Channelized
88-108 MHz: Analog VFO
Frequency stability: ? ppm
Mode: FM / WFM
Channels / memory management: 8 regular
1 priority
1 XTAL per channel
Power supply: 12-15 VDC (Fixed power cord)
Current drain / power consumption: Less than 725 mA @ 13.8 VDC
Antenna impedance / connector: 50-75 ohm / Two DIN41585 (Motorola)
Dimensions (W*H*D): 210*65*200 mm (8.27*2.56*7.87")
Weight: 1.98 Kg (4.36 lb)
Other features:

RECEIVER SECTION
Receiver system: Single conversion superheterodyne (WFM)
IF: 10.85 MHz
Double conversion superheterodyne (FM)
1st IF: 10.7 MHz
2nd IF: 455 KHz
Sensitivity: 79 MHz: 0.5 uV nominal
87-108 MHz: 2 uV nominal
166 MHz: 0.5 uV nominal
Selectivity: FM: 27 KHz (-6 dB)
40 KHz (-50 dB) nominal
Image rejection: 79 MHz: 45 dB
87-108 MHz: 45 dB
166 MHz: 35 dB
AF output power / speaker: 2.8 W at 10% distortion / 8 ohm
External speaker connector: 3.5 mm, 3.2-16 ohm
