4 trådlösa headset, True Diversity, Mottagare, Mixer, guldpläterade anslutningar

4 trådlösa mikrofoner med true diversity och guldpläterade anslutningar. Hög ljudkvalitet!
Går även på 12V DC. Se pdf på hemsidan

Chord QU4 Quad Bodypack UHF Mic system

Product Overview

XU series wireless microphone systems offer pro-level features in a compact receiver with premium microphone transmitters. Supplied as a half-width 1U rack receiver with 4 channels of bodypack transmitters with neckband and lavalier mic option. The receiver is a true diversity type with dual antennas and internal distribution for minimizing dropouts. The front panel has a volume control and indicator LEDs per channel alongside a colour TFT display with level indications for each channel and settings for channel frequencies and colours.
Main Features

• Compact half-width rack receiver
• True diversity antennas with internal distro for reliable reception
• 10-Groups of 9 selectable UHF carrier frequencies

XU series UHF Microphone System

XU series wireless microphone system offer pro-level features in a compact receiver with premium microphone transmitters. Supplied as a half-width 1U rack receiver with 1, 2 or 4 channels of either handheld microphones or bodypack transmitters with a neckband and lavalier mic option. The receiver is a true diversity type with dual antennas and internal distribution for minimizing dropouts. The front panel has a volume control and indicator LEDs per channel alongside a colour TFT display with level indications for each channel and settings for channel frequencies and colours. Each transmitter also has its own LCD display for frequency and battery status, with a backlight that can be set to one of 6 colours for identification. Carrier frequencies are arranged in 10 groups with carriers in both the UK/EU license-free UHF and PMSE licensed duplex gap UHF bands. Each set is supplied with hardware for mounting into a 1U rack space with extension cables to enable front mounting of the antennas. For a wireless microphone system with straightforward operation and intuitive features, the XU series delivers freedom and reliable operation to vocalists, presenters and instructors in a compact and convenient package.
Compact half-width rack receiver
True diversity antennas with internal distro for reliable reception
10 groups of 9 selectable UHF carrier frequencies
Selectable backlight colours for each channel
1, 2 or 4 x XLR outputs + 1 x 6.3mm mix output
Settings sync I.R. from receiver to transmitters
Colour TFT display for settings menu
Weight : lavalier microphone
23g
Dimensions : lavalier microphone
27 x 12mmØ
Weight : neckband microphone
28g
Dimensions : neckband microphone
180 x 140 x 60mm
Weight : beltpack transmitter
74g (no battery)
Dimensions : beltpack transmitter
90 x 60 x 25mm
Weight : handheld transmitter
N/A
Dimensions : handheld transmitter
N/A
Power supply
12-18Vdc, 1000mA (mains adaptor supplied)
Batteries
2 x AA per transmitter
Carrier frequencies
823-832 / 863-865MHz
Wireless range
Up to 60m
Antenna connection
2 x BNC
Dimensions : receiver
205 x 205 x 44mm
Weight : receiver
755g
Packaging type
Gift Box
Package dims
70 x 325 x 490mm
Package quantity
1 unit
Nett weight
2.0300kg
Gross weight
2.4550kg

CHORD XU4 Quad Bodypack UHF Microphone System
